Pure sine wave output
-
Power ON / OFF remote control (Green Terminal)
-
Input & output fully isolation
-
Temperature & load controlled cooling fan
-
User friendly interface
-
Output frequency 50/60 Hz selectable by DIP switch
-
Output voltage DIP switch selectable
-
Power saving mode by variable resister
-
3-color LED status indicators
-
Input protection：Reverse Polarity (Fuse) / Under Voltage / Over Voltage
-
Output protection：Short Circuit / Overload / Over Temperature
-
E13 / UL / CE / FCC approved
Main Features
◎New generation pure sine wave inverter ◎ Higher efficiency, high power density ◎ Selectable output voltage and frequency ◎ Robust aluminum case
AC Output Voltage
200/220/230/240 VAC
Output Waveform
100V series：Pure Sine Wave (THD
Frequency
50/60 Hz ± 0.5% (Dip switch selectable)
DC Output Voltage Range
─
DC Input Voltage Range
10.5~16.5VDC
Operating Temperature
-20~40℃, Power De-rating from 40°C~60°C
Storage Temperature
-30~70℃
Safety
CE / FCC / UL (only for 112/124 GFCI receptacles) / E13
Dimension (WxHxD)
200x83x330 mm
Socket Type
Saudi Arabia
Shipping Dimensions.
38cm x 25cm x 16cm (LxWxH)
