Off-road Factory Race Series bump stops were developed with top off-road racing teams to provide precise control of the last few inches of suspension travel. By applying our race-proven damping technology in a purpose-built, stand-alone component, you can use every bit of suspension travel without harsh bottoming.
The built-in FOX Air Valve (FAV) Valve allows precise nitrogen charge adjustments to provide a wide range of bottoming control. The durable construction and replaceable strike pad are built to take the abuse while providing predictable and quiet operation.
Features |
NEW proprietary Cerakote® protective ceramic coating over zinc plated basecoat |
|
Hard chome plated 4130 chromoly steel shaft |
|
Owner serviceable and rebuildable |
|
JM92 MIL-SPEC oil developed specifically for off-road racing |
|
Black Anodized CNC Machined Aluminum Components |
Extended |
11.440 |
Compressed |
8.900 |
Top Mount |
Pinch |
Bottom Mount |
None |
Reservoir |
Emulsion |
Replaces Part Number |
980-02-311 |
Valving |
807-24-007 |
